Gets me out to the mooring a lot quicker, although the row is long - it can be enjoyable too in some conditions. She is running pretty nice for an old single stroke(33 lb) motor, sometimes starting on the first few pulls.
The lower cover I currently do not have on, mainy due to how hard it is to spray gas/oil mix in a pinch into the carburetor with it on. I rebuilt the carburetor with parts (Carb Kit DI-52030) from I replaced the black gas line with a clear line and have an inline fuel filter which I highly recommend.
Ted williams outboard motor carb carburetor kit manual#
Anyone else working on one of these?Īfter reading through a manual snagged off of Ebay, I found that the recommended gas to oil mixture is 24:1, replaced the spark plug(manual calls for Champion J13Y, I used substitute Champion RJ14YC), recut the high tension lead wire and rebooted the spark plug cover. Your motor uses an aircooled Tecumseh power head with a water. New Carburetor Rebuild kit Carb Rebuild Rebuild Kit Set with Gasket Parts for Eska Sears Ted Williams Tecumseh Outboard 1961-1987 Motor Motorcycle Replacement Parts Kits and Parts 54.27 54. Parts should be available at certified parts corp. If you have had good luck with your motor you should rebuild the carb.There is a fuel pump element in the mounting flange on the carb. With some starter fluid, was able to start the engine for a few seconds until it burned up(note: better to spray gas/oil mix from old spray bottle, as starter fluid doesn't have required oil lubrication) - Next steps will be cleaning/rebuilding the carb, and possibly cleaning some carbon off the cylinder head and replacing the head gasket if I can find the part. Re: 1974 Ted Williams 7.5HP Carb/Fuel Issues - Help requested These motors have a poor reputation. First steps - drain old gas, clean or replace fuel lines, make sure spark plug is working correctly, and check compression. It is a two-stroke, and a great introduction to working on outboard motors for me. Let me know how I can help out.Started working on an old outboard I aquired with the dinghy, its a 1972 Sears Ted Williams (217.59462 made by Eska) 4.5 HP outboard.
Ted williams outboard motor carb carburetor kit free#
If a new one is inserted at the incorrect angle, it still will not run.įeel free to send me a private message if you have any other questions. Nos Nla Sears Eska Clinton Outboard Gear Housing Cap Gasket 9651296015. Di 52027 Eska Sears Ted Williams Tecumseh Outboard Motor Carb Kit 1961- 1987. When that pops, the motor will no longer run from an external gas tank. For Eska Sears Ted Williams Tecumseh Outboard Motor Carburetor Kit 1961- 1987. Even their carburetors were strange with a little balloon for a fuel pump. The one thing I recall is that the little motors ran well when they ran, but when they stopped, it was easier to take them to the scrap yard than it was to repair them. I had the opportunity to work on a number of these motors in the late 1990’s when I was laid off and needed some income to stay afloat (pun not intended). I actually am guilty of having an "ESKA Toss" many years ago at a Lake Catherine wet meet because it was the only motor that would not anger one of our members when we threw one into the lake (not to worry, we had a rope on each motor and did not leave them in the lake). This forum is probably not the best source for information on the ESKA outboard because nobody that I know collects the Tecumseh powered air-cooled motors from ESKA.
Ted williams outboard motor carb carburetor kit manuals#
The last company that I dealt with that had manuals and parts for the ESKA outboard was Certified Parts Corporation in Janesville, Wisconsin. Rated at 5hp, it is an air-cooled motor however, if it is similar to some I have worked on in the past, there is still a water pump impeller in the lower end that pushes water to the bottom of the powerhead to condense gases and to keep heat from building up under the top cowlings. I am not an expert on your outboard, but I am fairly certain that it is an ESKA outboard manufactured in 1974 for Sears in Canada.
